6900

Bearing No.	d	D	B	r (min.)	Basic Load Rating(KN)		Limiting Speed		Weight
					Dynamic	Static	Grease	Oil	Kg(pc)
					Cr	Cor	r/min	r/min	Kg(pc)
6900	10	22	6	0.3	2.7	1.25	34000	41000	0.01
6901	12	24	6	0.3	2.9	1.45	31000	36000	0.011
6902	15	28	7	0.3	4.3	2.25	26000	30000	0.017
6903	17	30	7	0.3	4.6	2.55	23000	28000	0.018
6904	20	37	9	0.3	6.35	3.7	19000	23000	0.036
6905	25	42	9	0.3	7	4.55	16000	19000	0.041
6906	30	47	9	0.3	7.25	5	14000	17000	0.045
6907	35	55	10	0.6	10.9	7.75	12000	14000	0.073
6908	40	62	12	0.6	13.7	9.95	11000	13000	0.112
6909	45	68	12	0.6	14.1	10.9	9700	11000	0.132
6910	50	72	12	0.6	14.5	11.7	9000	11000	0.133
6911	55	80	13	1	16.6	14.1	8100	9600	0.185
6912	60	85	13	1	20.2	17.3	7500	8900	0.192
6913	65	90	13	1	17.4	16.1	7100	8400	0.211
6914	70	100	16	1	23.7	21.2	6400	7600	0.342
6915	75	105	16	1	24.4	22.6	6100	7200	0.363
6916	80	110	16	1	25	24	5700	6800	0.382
6917	85	120	18	1.1	31.9	29.6	5300	6300	0.535
6918	90	125	18	1.1	32.8	31.6	5100	6000	0.565
6919	95	130	18	1.1	33.7	33.5	4800	5700	0.705
6920	100	140	20	1.1	45	41.9	4500	5300	0.96
6921	105	145	20	1.1	46.5	44.8	4300	5100	1
6922	110	150	20	1.1	47.9	47.8	4100	4900	1.04
6924	120	165	22	1.1	57.2	56.9	3800	4400	1.41
6926	130	180	24	1.5	69.6	70	3400	4100	1.86
6928	140	190	24	1.5	71.3	74.8	3200	3800	1.98
