6300

Bearing No.	d	D	B	r (min.)	Basic Load Rating(KN)		Limiting Speed		Weight
					Dynamic	Static	Grease	Oil	Kg(pc)
					Cr	Cor	r/min	r/min	Kg(pc)
6300	10	35	11	0.6	8.1	3.45	22000	27000	0.053
6301	12	37	12	1	9.7	4.2	20000	25000	0.06
6302	15	42	13	1	11.4	5.45	17000	20000	0.082
6303	17	47	14	1	13.6	6.65	15000	18000	0.115
6304	20	52	15	1.1	15.9	7.85	14000	17000	0.144
6305	25	62	17	1.1	20.6	11.3	11000	13000	0.232
6306	30	72	19	1.1	26.7	15	9600	12000	0.346
6307	35	80	21	1.5	33.4	19.3	8500	10000	0.457
6308	40	90	23	1.5	40.7	24	7700	9200	0.633
6309	45	100	25	1.5	48.9	29.5	6800	8100	0.833
6310	50	110	27	2	62	38.3	6100	7300	1.07
6311	55	120	29	2	71.6	45	5600	6700	1.37
6312	60	130	31	2.1	81.9	52.2	5200	6200	1.7
6313	65	140	33	2.1	92.7	59.9	4800	5800	2.08
6314	70	150	35	2.1	104	68.2	4500	5400	2.52
6315	75	160	37	2.1	113	77.2	4200	5000	3.02
6316	80	170	39	2.1	123	86.7	3900	4700	3.59
6317	85	180	41	3	133	96.8	3700	4400	4.23
6318	90	190	43	3	143	107	3500	4200	4.91
6319	95	200	45	3	153	119	3300	4000	5.67
6320	100	210	47	3	173	141	3000	3600	7
6321	105	225	49	3	184	153	2900	3500	8.05
6322	110	240	50	3	205	180	2700	3200	9.54
6324	120	260	55	3	207	135	2500	3000	12.5
6326	130	280	58	4	229	214	2300	2700	15.1
6328	140	300	62	4	253	246	2100	2500	19.4
